Introduction

In this blog, we will demonstrate how to proactively monitor a web server EC2 security group for any traffic rule changes using Lambda along with a few other services. If we detect any unauthorized changes, we will then undo them using Lambda. There will also be an SNS notification sent out to the admins, which is us.

In this activity we will be working with the following AWS services:

Lambda
SNS
CloudTrail
CloudWatch
CloudFormation
EC2
VPC
S3

This scenario is a working example of how we can use Lambda to perform various operational tasks within our account, especially ones that maintain our security posture.

Architecture

The below diagram illustrates the high-level architecture and the steps to be followed in sequence.

Prerequisites

An AWS account
An existing VPC such as the default VPC

Steps

Create Your CloudTrail Trail

Navigate to the CloudTrail service. From the left-hand menu, access Trails and click on Create trail.

Specify your desired name for the trail
For Storage location section, choose New S3 bucket and keep the default generated name. This will create an S3 bucket to load API event trail logs.
Enable CloudWatch Logs to create a log group to which the trail will send events.
Choose Event type as Management events
Choose API activity to log both Read and Write activities.
Leave other settings as is and finally click Create trail.

Deploy the CloudFormation Template

The CloudFormation template will create several resources:

A web security group that is monitored for any changes
An IAM role attached to the Lambda function as an execution role with permissions to remove any changes to the security group inbound rules.
A Lambda Permission which allows CloudWatch Events to invoke the Lambda function
A Lambda function that revokes any changes to the web security group and publishes a message to an SNS topic
A CloudWatch Event Rule that captures security group change events and triggers the Lambda function (Note: CloudWatch Events is now Amazon EventBridge)
SNS topic with an email subscription to send an email notification when the Lambda function is invoked

Follow the below steps to deploy these resources:

Using your preferred code editor, create a .yaml file with the below CloudFormation template.

---
AWSTemplateFormatVersion: 2010-09-09
Description: |
  Creates the resources necessary to create a rule to monitor and
  auto-mitigate security group change events

Metadata:
  License:
    Description: |
      Copyright 2017 Amazon.com, Inc. or its affiliates. All Rights Reserved.

      Licensed under the Apache License, Version 2.0 (the "License"). You may not use this file except in compliance with the License. A copy of the License is located at

          http://aws.amazon.com/apache2.0/

      or in the "license" file accompanying this file. This file is distributed on an "AS IS" BASIS, WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied. See the License for the specific language governing permissions and limitations under the License.

  AWS::CloudFormation::Interface:
    ParameterGroups:
      - Label:
          default: Settings
        Parameters:
          - NotificationEmailAddress

    ParameterLabels:
      NotificationEmailAddress:
        default: Send notifications to

Parameters:

  NotificationEmailAddress:
    Description: |
      This is the email address that will receive change notifications. You will
      receive a confirmation email that you must accept before you will receive
      notifications.
    Type: String

Conditions:

  AddEmailNotificationSubscription:
    !Not [!Equals [!Ref NotificationEmailAddress, ""]]

Resources:

  WebServerSecurityGroup:
    Type: AWS::EC2::SecurityGroup
    Properties:
      GroupDescription: Allow HTTPS access to web servers
      SecurityGroupIngress:
      - IpProtocol: tcp
        FromPort: 443
        ToPort: 443
        CidrIp: 0.0.0.0/0
      Tags:
        - Key: Name
          Value: Web Server Security Group

  SecurityGroupChangeAutoResponseRole:
    Type: AWS::IAM::Role
    Properties:
      AssumeRolePolicyDocument:
        Version: 2012-10-17
        Statement:
          -
            Effect: Allow
            Principal:
              Service: lambda.amazonaws.com
            Action:
              - sts:AssumeRole
      ManagedPolicyArns:
        - arn:aws:iam::aws:policy/service-role/AWSLambdaBasicExecutionRole
      Policies:
        -
          PolicyName: SecurityGroupModification
          PolicyDocument:
            Version: 2012-10-17
            Statement:
              -
                Sid: AllowSecurityGroupActions
                Effect: Allow
                Action:
                  - ec2:RevokeSecurityGroupIngress
                Resource: !Sub arn:aws:ec2:${AWS::Region}:${AWS::AccountId}:security-group/${WebServerSecurityGroup.GroupId}
              -
                Sid: AllowSnsActions
                Effect: Allow
                Action:
                  - sns:Publish
                Resource: !Ref SnsTopicForCloudWatchEvent

  SecurityGroupChangeAutoResponse:
    Type: AWS::Lambda::Function
    Properties:
      Description: Responds to security group changes
      Handler: index.lambda_handler
      MemorySize: 1024
      Role: !GetAtt SecurityGroupChangeAutoResponseRole.Arn
      Runtime: python3.9
      Timeout: 60
      Environment:
        Variables:
          security_group_id: !GetAtt WebServerSecurityGroup.GroupId
          sns_topic_arn: !Ref SnsTopicForCloudWatchEvent
      Code:
        ZipFile: |
          import os, json, boto3

          #===============================================================================
          def lambda_handler(event, context):

              print(event)

              # Ensure that we have an event name to evaluate.
              if 'detail' not in event or ('detail' in event and 'eventName' not in event['detail']):
                  return {"Result": "Failure", "Message": "Lambda not triggered by an event"}

              # Remove the rule only if the event was to authorize the ingress rule for the given
              # security group that was injected during CloudFormation execution.
              if (event['detail']['eventName'] == 'AuthorizeSecurityGroupIngress' and
                  event['detail']['requestParameters']['groupId'] == os.environ['security_group_id']):
                  result = revoke_security_group_ingress(event['detail'])

                  message = "AUTO-MITIGATED: Ingress rule removed from security group: {} that was added by {}: {}".format(
                          result['group_id'],
                          result['user_name'],
                          json.dumps(result['ip_permissions'])
                          )

                  boto3.client('sns').publish(
                    TargetArn = os.environ['sns_topic_arn'],
                    Message = message,
                    Subject = "Auto-mitigation successful"
                    )


          #===============================================================================
          def revoke_security_group_ingress(event_detail):

              request_parameters = event_detail['requestParameters']

              # Build the normalized IP permission JSON struture.
              ip_permissions = normalize_paramter_names(request_parameters['ipPermissions']['items'])

              response = boto3.client('ec2').revoke_security_group_ingress(
                  GroupId = request_parameters['groupId'],
                  IpPermissions = ip_permissions
                  )

              # Build the result
              result = {}
              result['group_id'] = request_parameters['groupId']
              result['user_name'] = event_detail['userIdentity']['arn']
              result['ip_permissions'] = ip_permissions

              return result


          #===============================================================================
          def normalize_paramter_names(ip_items):

              # Start building the permissions items list.
              new_ip_items = []

              # First, build the basic parameter list.
              for ip_item in ip_items:

                  new_ip_item = {
                      "IpProtocol": ip_item['ipProtocol'],
                      "FromPort": ip_item['fromPort'],
                      "ToPort": ip_item['toPort']
                  }

                  #CidrIp or CidrIpv6 (IPv4 or IPv6)?
                  if 'ipv6Ranges' in ip_item and ip_item['ipv6Ranges']:
                      # This is an IPv6 permission range, so change the key names.
                      ipv_range_list_name = 'ipv6Ranges'
                      ipv_address_value = 'cidrIpv6'
                      ipv_range_list_name_capitalized = 'Ipv6Ranges'
                      ipv_address_value_capitalized = 'CidrIpv6'
                  else:
                      ipv_range_list_name = 'ipRanges'
                      ipv_address_value = 'cidrIp'
                      ipv_range_list_name_capitalized = 'IpRanges'
                      ipv_address_value_capitalized = 'CidrIp'

                  ip_ranges = []

                  # Next, build the IP permission list.
                  for item in ip_item[ipv_range_list_name]['items']:
                      ip_ranges.append(
                          {ipv_address_value_capitalized : item[ipv_address_value]}
                          )

                  new_ip_item[ipv_range_list_name_capitalized] = ip_ranges

                  new_ip_items.append(new_ip_item)

              return new_ip_items

  SecurityGroupChangeAutoResponseLambdaPermission:
    Type: AWS::Lambda::Permission
    Properties:
      Action: lambda:InvokeFunction
      Principal: events.amazonaws.com
      FunctionName: !Ref SecurityGroupChangeAutoResponse

  TriggeredRuleForSecurityGroupChangeAutoResponse:
    Type: AWS::Events::Rule
    Properties:
      #Name: SecurityGroupChangeAutoResponse
      Description: Responds to security group change events
      EventPattern:
        detail:
          eventSource:
            - ec2.amazonaws.com
          eventName:
            - AuthorizeSecurityGroupIngress
            - AuthorizeSecurityGroupEgress
            - RevokeSecurityGroupEgress
            - RevokeSecurityGroupIngress
            - CreateSecurityGroup
            - DeleteSecurityGroup
      State: ENABLED
      Targets:
        -
          Arn: !GetAtt SecurityGroupChangeAutoResponse.Arn
          Id: TargetFunctionV1

  SnsTopicForCloudWatchEvent:
    Type: AWS::SNS::Topic
    Properties:
      DisplayName: Broadcasts message to subscribers

  SnsTopicSubscriptionForCloudWatchEvent:
    Type: AWS::SNS::Subscription
    Condition: AddEmailNotificationSubscription
    Properties:
      TopicArn: !Ref SnsTopicForCloudWatchEvent
      Endpoint: !Ref NotificationEmailAddress
      Protocol: email

Navigate to CloudFormation service and click on Create stack.
Click on Upload a template file from the Specify template section and choose the locally created .yaml file, then click Next.
Specify your desired name of the stack.
Enter your email address in the Parameters section under Send notifications to parameter.
Leave everything else as is and click on Submit at the end.
Once the stack status changes to CREATE_COMPLETE, you should receive an email from AWS to confirm the subscription to the SNS topic. Click on Confirm subscription link within the email bod

Test and Verify The Solution

Head to EC2 in the console and access Security Groups under Network & Security. Select the created Web Server Security Group and click on Edit inbound rules.

Click on Add rule. Select SSH as Type and Anywhere-IPv4 as the Source. Then click on Save rules.

Once this change is done, CloudTrail will catch this event and send it to CloudWatch, which will trigger the deployed event rule and pass the data to the Lambda function. The function will parse that data and do two things; it will remove the rule we added, and also publish to the SNS topic which will send an email to the defined email address.

Refresh the inbound rules and you will notice the newly added rule has been immediately removed!

You will also receive a notification email mentioning that the added ingress rule has been removed as shown below.

We can also view the metrics of the successful lambda function invocation from the Monitor menu of the function as shown below.

Until next time...

Thanks for reading!
